An infiltration trench (a.k.a. infiltration galley) is a rock-filled trench with no outlet that receives stormwater runoff. Stormwater runoff passes through some combination of pretreatment measures, such as a swale and detention basin, and into the trench. There, runoff is stored in the void space between the stones and infiltrates through the bottom and into the soil matrix. The primary pollutant removal mechanism of this practice is filtering through the soil.

infiltration trench

An infiltration trench (a.k.a. infiltration galley) is a rock-filled trench with no outlet that receives stormwater runoff. Stormwater runoff passes through some combination of pretreatment measures, such as a swale and detention basin, and into the trench. There, runoff is stored in the void space between the stones and infiltrates through the bottom and into the soil matrix. The primary pollutant removal mechanism of this practice is filtering through the soil.

best management practice pollutant discharge elimination green development

Author(s)Jane Hawkey
Author CompanyIntegration and Application Network
Date Created2013-05-13
AlbumHuman > Management/Restoration
TypePhoto
Dimensions2304 x 3072
Filesize5.2 MB
Number of Downloads261
Filetype(s) JPG
LicenseAttribution-ShareAlike 4.0 International (CC BY-SA 4.0)
Required AttributionJane Hawkey, Integration and Application Network (ian.umces.edu/media-library)
