Illustration of a flow deflector, or J-hook Vane, used to dissipate stream energy and reduce bank erosion.

Civil Engineering: Flow deflector (J-hook Vane)

Illustration of a flow deflector, or J-hook Vane, used to dissipate stream energy and reduce bank erosion.

science research ecosystem base modifier flow deflector measurement discharge landscape dam river stream j-hook vane restoration

Author(s)Tracey Saxby
Author CompanyIntegration and Application Network
Date Created2010-06-22
AlbumHuman > Development/Infrastructure
TypeSymbol
Project(s)U.S. Army Corps of Engineers: symbol requests and development
Dimensions502 x 192
Filesize48.4 kB (svg)   36.1 kB (png)
Number of Downloads601
Filetype(s) SVG     PNG
LicenseAttribution-ShareAlike 4.0 International (CC BY-SA 4.0)
Required AttributionTracey Saxby, Integration and Application Network (ian.umces.edu/media-library)
