Conceptual diagram illustrating a mathematical model which represents nitrogen inputs and exports in coastal bays.

Nitrogen exchange in a coastal bay

Conceptual diagram illustrating a mathematical model which represents nitrogen inputs and exports in coastal bays.

diagram nitrogen management water quality nutrients sediment denitrification
